Autel MaxiPRO MP808S-TS 2024

The Autel MP808S-TS is an advanced tool for diagnosis and coding including TPMS valve coding. It offers complete diagnostics of all units on most European, Asian and American cars, combined with advanced service features. Unlike cheap universal devices, it is not limited to diagnostics within the OBD-II standard. Supports older vehicles (OBD-I). It can read the readiness code, reset service intervals, diagnose and regenerate DPF, perform basic throttle settings, reset automatic transmission adaptations, perform complete TPMS diagnostics, register battery, code the injectors, code keys and remotes and many other tasks. In addition to the engine unit, the automatic transmission, ABS, airbags, dashboard and other units in the car are also supported.

Autel 808 series also supports access to FCA Group units protected by the Security Gateway Module (SGW) without the need for a bypass - a subscription via AutoAuth is required.

TPMS Functions

Diagnostics is able to activate/read 99% of known TPMS sensors, read and clear TPMS errors, display manufacturer specific valve coding procedures, can also handle sensor learning even when replacing original sensors with Autel MX replacements.

• check - activate TPMS sensors to display ID, tire pressure, tire temperature, battery status and sensor location.

• diagnostics - displays system status, reads and clears any errors

• coding - when replacing original sensors with Autel MX sensors, can code these:

• copy by activation - will program the sensor ID obtained from the sensor

• copy via OBD-II - will program the sensor ID obtained from the TPMS unit

• copy by input - will allow manual input of the original sensor ID

• auto create - will create a random ID to program the sensor

• TPMS learning - this function is designed to program the newly created sensor ID into the TPMS unit - 3 ways of implementation
• if the original part number is known , this function allows Autel MX sensors to be activated and programmed. This method allows up to 20 sensors to be coded at once.

Updates

1-year free update is included in the price of the device. After this time you can still use the device, updates are not mandatory, but you will not have information and support for newer car models. For a price list of updates, click here.

Additional Equipment (not included)

• Autel MV480 videoscope (stand alone product)
• Autel MV105S videoscope
• Autel PS100 battery tester (stand alone product)
• Autel BT506 battery tester (stand alone product)

Quick Overview of Autel Models

• diagnostic and services functions: MK808S, MK808K-BT, MK808S-TS
• diagnostic and services functions and coding: MP808S, MP808S-TS, MP900, MP900BT, MP900TS
• advanced models: MK906BT, MK906 Pro, MK908P, MS Elite II
• TOP models: Ultra Lite, Ultra
• IMMO series: IM508, IM608

Why choose Autel MP808S-TS?

• offers all common diagnostic and service functions

• support of coding of units
• bluetooth VCI (vehicle communication interface)
• TPMS sensor coding integrated to tablet

Supported Vehicles (1996 - 2024)

Asian

Acura, Daewoo, Holden, Honda, Hyundai, Infiniti, Isuzu, Kia, Lexus, Mazda, Mitsubishi, Nissan, Scion, Subaru, Suzuki, Toyota.

European

Abarth, Alfa-Romeo, Audi, BMW, Citroen, Dacia, Fiat, Ford, Jaguar, Lancia, Land Rover, Maserati, Maybach, Mercedes, Mini, Opel, Peugeot, Porsche, Renault, Saab, Seat, Skoda, Smart, Sprinter, Vauxhall, Volvo, Volkswagen.

American

Ford, GM, Chrysler.

Supported languages

The device supports different languages. After receiving the device, send us the serial number and we will authorize the device for you in desired language. The translation may not be completely 100%. The scope of the translation is being extended and in our experience the translation is well usable and will make your work easier.

List of the supported languages: English, Arabic, Czech, Dutch, French, German, Hebrew, Indonesian English, Italian, Japanese, Korean, Persian, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Portuguese, Turkish, Thai, Vietnamese

Hardware Specification
