OBDStar MS70

Product detailed description

The OBDStar MS70 supports almost all common motorcycle brands and offers intelligent, professional-level diagnostics, including comprehensive diagnostic and service functions. The advantage is the wide support of different motorcycle brands. The instrument will detect faults, provide a technical bulletin, help with monitoring readings, diagnostic socket location and other features to help you diagnose accurately and efficiently. A great benefit is the wealth of supporting technical data such as interactive circuit diagrams, troubleshooting guides and more. Adapters are included for connection to various motorcycles.

Diagnostic Functions

• Identification of all control units
• Reading of fault codes for all units
• Erasing error codes of all units
• Display live data
• Tests of actuators
• Adaptation
• Coding

Service Functions

• Reset service intervals
• ABS settings
• Idle speed adjustment
• TPMS reset
• Reset transmission adaptations
• Basic throttle settings and more

Update

Get free updates for 1 year with purchase. After the free updates expire, no further updates are required. New updates can be purchased after the expiration of the existing ones at a better price. Updates can also be purchased at a later date after missing a certain period, however the price may be higher.

Why Choose OBDSTAR MS70?

• Diagnostics available for all common brands
• Complete diagnostic and service functions
• Accessories included

Supported Motorcycles

• Asian: AEON, BAJAJ, HARTFORD, HERO, HONDA, HYOSUNG, KAWASAKI, KYMCO, PGO, ROYAL ENFIELD, SUZUKI, SYM, TVS, YAMAHA
• European: APRILIA, BENELLI, BMW, DERBI, DUCATI, GILERA, HM, HUSQVARNA, KTM, MOTO GUZZI, PEUGEOT, PIAGGIO, ROYAL ALLOY, TRIUMPH, VESPA
• Chinese: CFMOTO, CHINA ABS, CHINA ENGINE, HAOJUE, QJBENELLI, SHINERAY, ZONTES
• American: ACELLERA, BRP, HARLEY-DAVIDSON, INDIAN

Supported Languages

The device supports English language only.

Hardware specifications

• Operating system: Android 5.1.1
• Processor: 4-core processor
• Memory - storage: 16 GB
• Display: 7" touch screen with 1024 x 600 pixel resolution
• operating temperature: -20 - 55 °C
• Storage temperature: -20 - 70°C
• Operating humidity: 5 - 95% (non-condensing)
• Battery capacity: 3700 mAh

Package contents

• OBDSTAR MS70
• OBD-II cable
• Power cable
• Cable for anchoring
• Multifunction jumpers
• 3-pin adapter for Aprilia, Ducati, Honda, KTM, Piaggio, Vespa, Yamaha motorcycles
• 4- and 6-pin adapter for Kawasaki motorcycles
• 6-pin adapter for Suzuki motorcycles
• 4-pin adapter for Honda motorcycles
• 3-, 3- and 4-pin adapter for Yamaha motorcycles
• 6-pin adapter for KTM motorcycles
• 6-pin adapter for AEON, Benelli motorcycles
• 3-pin adapter for SYM motorcycles
• 3-pin adapter for Kymco, Kawasaki motorcycles
• 4- and 6-pin adapter for Harley-Davidson
• 4-pin adapter for Ducati
• 8-pin adapter for Indian/Victory
• Charger
• User manual
